Android设置图片圆角的方法

RequestOptions options = new RequestOptions().error(R.drawable.img_load_failure).bitmapTransform(new RoundedCorners(30));//图片圆角为30
Glide.with(this).load(URL) //图片地址
    .apply(options)
    .into(ImagView);

RequestOptions requestOptions = new RequestOptions();
requestOptions.placeholder(R.drawable.ic_launcher_background);
requestOptions.circleCropTransform();
requestOptions.transforms( new RoundedCorners(30));
Glide.with(this).load(URL) //图片地址
    .apply(options)
    .into(ImagView);

RequestOptions options = new RequestOptions().centerCrop() .transform(new RoundTransform(this,30));
Glide.with(this).load(URL) //图片地址
    .apply(options)
    .into(ImagView);

public class RoundTransform extends BitmapTransformation {
 private static float radius = 0f;
 public RoundTransform(Context context) {
  this(context, 4);
 }

 public RoundTransform(Context context, int dp) {
  super(context);
  this.radius = Resources.getSystem().getDisplayMetrics().density * dp;
 }

 @Override
 protected Bitmap transform(BitmapPool pool, Bitmap toTransform, int outWidth, int outHeight) {
  Bitmap bitmap = TransformationUtils.centerCrop(pool, toTransform, outWidth, outHeight);
  return roundCrop(pool, bitmap);
 }

 private static Bitmap roundCrop(BitmapPool pool, Bitmap source) {
  if (source == null) return null;
  Bitmap result = pool.get(source.getWidth(), source.getHeight(), Bitmap.Config.ARGB_8888);
  if (result == null) {
   result = Bitmap.createBitmap(source.getWidth(), source.getHeight(), Bitmap.Config.ARGB_8888);
  }

  Canvas canvas = new Canvas(result);
  Paint paint = new Paint();
  paint.setShader(new BitmapShader(source, BitmapShader.TileMode.CLAMP, BitmapShader.TileMode.CLAMP));
  paint.setAntiAlias(true);
  RectF rectF = new RectF(0f, 0f, source.getWidth(), source.getHeight());
  canvas.drawRoundRect(rectF, radius, radius, paint);
  return result;
 }

 public String getId() {
  return getClass().getName()   Math.round(radius);
 }

 @Override
 public void updateDiskCacheKey(MessageDigest messageDigest) {

 }
}

<ImageView
  android:id="@ id/iv"
  android:layout_width="300dp"
  android:layout_height="300dp"
  android:layout_centerHorizontal="true"
  />

ImageView iv = findViewById(R.id.iv);
Bitmap bitmap =BitmapFactory.decodeResource(getResources(), R.drawable.fengjing);
  Bitmap outBitmap =getRoundBitmapByShader(bitmap, 500,300,20, 3);
  iv.setImageBitmap(outBitmap);

public class RoundRectImageView extends ImageView{

 private Paint paint;

 public RoundRectImageView(Context context) {
  this(context,null);
 }

 public RoundRectImageView(Context context, AttributeSet attrs) {
  this(context, attrs,0);
 }

 public RoundRectImageView(Context context, AttributeSet attrs, int defStyle) {
  super(context, attrs, defStyle);
  paint = new Paint();
 }

 /**
  * 绘制圆角矩形图片
  * @author caizhiming
  */
 @Override
 protected void onDraw(Canvas canvas) {
  Drawable drawable = getDrawable();
  if (null != drawable) {
   Bitmap bitmap = getBitmapFromDrawable(drawable);
//   Bitmap bitmap = ((BitmapDrawable) drawable).getBitmap();
   Bitmap b = getRoundBitmapByShader(bitmap,getWidth(),getHeight(), 50,0);
   final Rect rectSrc = new Rect(0, 0, b.getWidth(), b.getHeight());
   final Rect rectDest = new Rect(0,0,getWidth(),getHeight());
   paint.reset();
   canvas.drawBitmap(b, rectSrc, rectDest, paint);

  } else {
   super.onDraw(canvas);
  }
 }

 /**
  * 把资源图片转换成Bitmap
  * @param drawable
  * 资源图片
  * @return 位图
  */
 public static Bitmap getBitmapFromDrawable(Drawable drawable) {
  int width = drawable.getIntrinsicWidth();
  int height = drawable.getIntrinsicHeight();
  Bitmap bitmap = Bitmap.createBitmap(width, height, drawable
    .getOpacity() != PixelFormat.OPAQUE ? Bitmap.Config.ARGB_8888
    : Bitmap.Config.RGB_565);
  Canvas canvas = new Canvas(bitmap);
  //drawable.setBounds(-4, -4, width   4, height   4);
  drawable.draw(canvas);
  return bitmap;
 }

 public static Bitmap getRoundBitmapByShader(Bitmap bitmap, int outWidth, int outHeight, int radius, int boarder) {
  if (bitmap == null) {
   return null;
  }
  int width = bitmap.getWidth();
  int height = bitmap.getHeight();
  float widthScale = outWidth * 1f / width;
  float heightScale = outHeight * 1f / height;

  Matrix matrix = new Matrix();
  matrix.setScale(widthScale, heightScale);
  //创建输出的bitmap
  Bitmap desBitmap = Bitmap.createBitmap(outWidth, outHeight, Bitmap.Config.ARGB_8888);
  //创建canvas并传入desBitmap，这样绘制的内容都会在desBitmap上
  Canvas canvas = new Canvas(desBitmap);
  Paint paint = new Paint(Paint.ANTI_ALIAS_FLAG);
  //创建着色器
  BitmapShader bitmapShader = new BitmapShader(bitmap, Shader.TileMode.CLAMP, Shader.TileMode.CLAMP);
  //给着色器配置matrix
  bitmapShader.setLocalMatrix(matrix);
  paint.setShader(bitmapShader);
  //创建矩形区域并且预留出border
  RectF rect = new RectF(boarder, boarder, outWidth - boarder, outHeight - boarder);
  //把传入的bitmap绘制到圆角矩形区域内
  canvas.drawRoundRect(rect, radius, radius, paint);

  if (boarder > 0) {
   //绘制boarder
   Paint boarderPaint = new Paint(Paint.ANTI_ALIAS_FLAG);
   boarderPaint.setColor(Color.GREEN);
   boarderPaint.setStyle(Paint.Style.STROKE);
   boarderPaint.setStrokeWidth(boarder);
   canvas.drawRoundRect(rect, radius, radius, boarderPaint);
  }
  return desBitmap;
 }

}

/**
 * 通过BitmapShader实现圆形边框
 * @param bitmap
 * @param outWidth 输出的图片宽度
 * @param outHeight 输出的图片高度
 * @param radius 圆角大小
 * @param boarder 边框宽度
 */
public static Bitmap getRoundBitmapByShader(Bitmap bitmap, int outWidth, int outHeight, int radius, int boarder) {
 if (bitmap == null) {
  return null;
 }
 int height = bitmap.getHeight();
 int width = bitmap.getWidth();

 float widthScale = outWidth * 1f / width;
 float heightScale = outHeight * 1f / height;

 Matrix matrix = new Matrix();
 matrix.setScale(widthScale, heightScale);
 //创建输出的bitmap
 Bitmap desBitmap = Bitmap.createBitmap(outWidth, outHeight, Bitmap.Config.ARGB_8888);
 //创建canvas并传入desBitmap，这样绘制的内容都会在desBitmap上
 Canvas canvas = new Canvas(desBitmap);
 Paint paint = new Paint(Paint.ANTI_ALIAS_FLAG);
 //创建着色器
 BitmapShader bitmapShader = new BitmapShader(bitmap, Shader.TileMode.CLAMP, Shader.TileMode.CLAMP);
 //给着色器配置matrix
 bitmapShader.setLocalMatrix(matrix);
 paint.setShader(bitmapShader);
 //创建矩形区域并且预留出border
 RectF rect = new RectF(boarder, boarder, outWidth - boarder, outHeight - boarder);
 //把传入的bitmap绘制到圆角矩形区域内
 canvas.drawRoundRect(rect, radius, radius, paint);

 if (boarder > 0) {
  //绘制boarder
  Paint boarderPaint = new Paint(Paint.ANTI_ALIAS_FLAG);
  boarderPaint.setColor(Color.GREEN);
  boarderPaint.setStyle(Paint.Style.STROKE);
  boarderPaint.setStrokeWidth(boarder);
  canvas.drawRoundRect(rect, radius, radius, boarderPaint);
 }
 return desBitmap;
}

/**
 * 通过BitmapShader实现圆形边框
 * @param bitmap
 * @param outWidth 输出的图片宽度
 * @param outHeight 输出的图片高度
 * @param boarder 边框大小
 */
public static Bitmap getCircleBitmapByShader(Bitmap bitmap, int outWidth, int outHeight, int boarder) {
int radius;
int width = bitmap.getWidth();
int height = bitmap.getHeight();
float widthScale = outWidth * 1f / width;
float heightScale = outHeight * 1f / height;

Bitmap desBitmap = Bitmap.createBitmap(outWidth, outHeight, Bitmap.Config.ARGB_8888);
if (outHeight > outWidth) {
 radius = outWidth / 2;
} else {
 radius = outHeight / 2;
}
//创建canvas
Canvas canvas = new Canvas(desBitmap);
Paint paint = new Paint(Paint.ANTI_ALIAS_FLAG);
BitmapShader bitmapShader = new BitmapShader(bitmap, Shader.TileMode.CLAMP, Shader.TileMode.CLAMP);
Matrix matrix = new Matrix();
matrix.setScale(widthScale, heightScale);
bitmapShader.setLocalMatrix(matrix);
paint.setShader(bitmapShader);
canvas.drawCircle(outWidth / 2, outHeight / 2, radius - boarder, paint);
if (boarder > 0) {
 //绘制boarder
 Paint boarderPaint = new Paint(Paint.ANTI_ALIAS_FLAG);
 boarderPaint.setColor(Color.GREEN);
 boarderPaint.setStyle(Paint.Style.STROKE);
 boarderPaint.setStrokeWidth(boarder);
 canvas.drawCircle(outWidth / 2, outHeight / 2, radius - boarder, boarderPaint);
}
return desBitmap;
}
