vue使用天地图、openlayers实现多个底图叠加显示效果

cnpm i -S ol
#或者
npm install ol

<script>
    // openlayers地图
import "ol/ol.css";
import {
  Icon,
  Style,
  Stroke
} from "ol/style";
import 'ol/ol.css'
import Map from "ol/Map";
import View from "ol/View";
import TileLayer from "ol/layer/Tile";
import XYZ from "ol/source/XYZ";
import { get as getProjection } from "ol/proj.js";
import { getBottomLeft, getTopRight } from 'ol/extent.js'
import { Vector as SourceVec } from 'ol/source';
import { Vector as LayerVec } from 'ol/layer';
import Overlay from "ol/Overlay";//弹窗
import {Point} from "ol/geom";
import {Feature} from "ol";
import { defaults as defaultControls } from "ol/control";//默认缩放
import {FullScreen,ScaleLine} from "ol/control";//全屏，比例尺控件
import TileGrid from 'ol/tilegrid/TileGrid';
import { LineString, Polygon } from 'ol/geom.js'
import { setTimeout } from 'timers';
import {Polyline} from "ol/format";
// import { vectorContext } from "ol/render";
import { getVectorContext } from "ol/render";
import {defaults as defaultInteractions} from 'ol/interaction';//旋转

export default {
        data(){
            tk:"密钥",
            center:{
                longitude:"",
                latitude:""
            },
            map:null,
        },
        methods:{
            initMap() {
              let defaultsMap = {
                tileUrl1:"图层地址1",
                tileUrl2:"图层地址2",
                tileUrl3:"图层地址3",
                origin: [-400, 400],
                zoom: 5,
                resolutions: [
                      //根据项目需要设置
                ],
                fullExtent: [
                          //根据项目需要设置
                ],
                inters: [1000, 100],
                center: [this.center.longitude, this.center.latitude],
                projection: getProjection("EPSG:4326")
              };
              // let projection = getProjection('EPSG:4326');

              // 底图天地图注记  cta——道路 中文注记
              let baseLayer = new TileLayer({
                title: "天地图",
                source: new XYZ({
                  url:"http://t4.tianditu.com/DataServer?T=cva_w&x={x}&y={y}&l={z}&tk="  this.tk
                 }),
                  zIndex: 2
          });
      //天地图路网
              let roadLayer = new TileLayer({
                    title: "天地图路网",
                    source: new XYZ({
                        projection: defaultsMap.projection,
                        url:"http://t4.tianditu.com/DataServer?T=vec_c&x={x}&y={y}&l={z}&tk="  this.tk
                    }),
                    zIndex: 1
              });


              // 加载地图层mapservice

              let tileGrid = new TileGrid({
                tileSize: 256,
                origin: defaultsMap.origin,
                extent: defaultsMap.fullExtent,
                resolutions: defaultsMap.resolutions
              });

              // 航道图层
              let cjinobeaconMap = new TileLayer({
                  source: new XYZ({
                      tileGrid: tileGrid,
                      projection: defaultsMap.projection,
                      url: defaultsMap.tileUrl1
                    }),
                    zIndex: 9
              });
              // 线图层
              let framesMap = new TileLayer({
                    source: new XYZ({
                      tileGrid: tileGrid,
                      projection: defaultsMap.projection,
                      url: defaultsMap.tileUrl2
                    }),
                    zIndex: 10
              });

              // 水深图层
              let soundgMap = new TileLayer({
                    source: new XYZ({
                      tileGrid: tileGrid,
                      projection: defaultsMap.projection,
                      url: defaultsMap.tileUrl3
                    }),
                    zIndex: 11
              });


              // 加载地图
              this.map = new Map({
                    target: "trajecttoryMap",
                    controls: defaultControls().extend([
                      new FullScreen(),
                      new ScaleLine({
                        units: "metric"
                      })
                  // new ZoomSlider()
                ]),
                interactions: defaultInteractions({
                  pinchRotate: false // 移动端禁止地图旋转
                }),
                loadTilesWhileAnimating: true,
                layers: [baseLayer, roadLayer, cjinobeaconMap, framesMap, soundgMap],
                //overlays: [this.overlay], // 把弹窗加入地图
                view: new View({
                      projection: defaultsMap.projection,
                      center: defaultsMap.center,
                      extent: defaultsMap.fullExtent,
                      // resolutions: defaultsMap.resolutions,
                      zoom: 14,
                      minZoom: 7,
                      maxZoom:17
                })
              });

            },
        },
        mounted(){
            this.initMap();
        }
}
</script>
