Android SearchView搜索控件使用方法详解

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout
   xmlns:android="http://schemas.android.com/apk/res/android"
   android:layout_width="match_parent"
   android:layout_height="match_parent">

   <ListView
      android:layout_height="match_parent"
      android:layout_width="match_parent"
      android:id="@ id/mainListView1"/>

</LinearLayout>

public class MainActivity extends AppCompatActivity
 {
   private ListView mListView;
   private ArrayAdapter mArrayAdapter;
   private String[]data={"a同学","b同学","c同学","d同学","A宿舍","B学校","C食堂","D教室","AA制"};
   private SearchView mSearchView;

   @Override
   protected void onCreate(Bundle savedInstanceState) {
      super.onCreate(savedInstanceState);
      setContentView(R.layout.activity_main);

      mArrayAdapter=new ArrayAdapter<String>(this,android.R.layout.simple_expandable_list_item_1,data);
      mListView=findViewById(R.id.mainListView1);
      mListView.setAdapter(mArrayAdapter);
   }

   @Override
   public boolean onCreateOptionsMenu(Menu menu)
   {
      getMenuInflater().inflate(R.menu.menu,menu);
      MenuItem MenuItem=menu.findItem(R.id.action_search);
      mSearchView=(SearchView) MenuItemCompat.getActionView(MenuItem);

      mSearchView.setQueryHint("请输入关键词");
      mSearchView.setOnQueryTextListener(new SearchView.OnQueryTextListener(){

            @Override
            public boolean onQueryTextSubmit(String p1)
            {
               //点击搜索按钮事件

               //收起键盘
               mSearchView.clearFocus();
               //收起搜索框
               mSearchView.onActionViewCollapsed();
               return false;
            }

            @Override
            public boolean onQueryTextChange(String p1)
            {
               //当搜索框的文字内容发生变化时调用
               mArrayAdapter.getFilter().filter(p1);
               return false;
            }
         });

      return super.onCreateOptionsMenu(menu);
   }

}

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android"
   xmlns:app="http://schemas.android.com/apk/res-auto">

   <item
      android:id="@ id/action_search"
      app:actionViewClass="android.support.v7.widget.SearchView"
      app:showAsAction="ifRoom" />

   <item
      android:id="@ id/action_settings"
      app:showAsAction="never"/>

</menu>

try {     //--拿到字节码
      Class<?> argClass = mSearchView.getClass();
      //--指定某个私有属性,mSearchPlate是搜索框父布局的名字
      Field ownField = argClass.getDeclaredField("mSearchPlate");
      //--暴力反射,只有暴力反射才能拿到私有属性
      ownField.setAccessible(true);
      View mView = (View) ownField.get(mSearchView);
      //--设置背景
      mView.setBackgroundColor(Color.TRANSPARENT);
    } catch (Exception e) {
      e.printStackTrace();
}

int searchPlateId = mSearchView.getContext().getResources()
   .getIdentifier("android:id/search_plate", null, null);
View searchPlate = mSearchView.findViewById(searchPlateId);
if (searchPlate != null)
{
   int searchTextId = searchPlate.getContext().getResources()
   .getIdentifier("android:id/search_src_text", null, null);

   //自定义文本颜色
   TextView searchText = (TextView) searchPlate.findViewById(searchTextId);
   if (searchText != null)
   {
      searchText.setTextColor(Color.WHITE);
      searchText.setHintTextColor(Color.WHITE);
   }
try
{
   //自定义光标颜色
   Field mCursorDrawableRes=TextView.class.getDeclaredField("mCursorDrawableRes");
   mCursorDrawableRes.setAccessible(true);
   mCursorDrawableRes.set(searchText, R.drawable.cursor_color);
}
catch (Exception e){}
}

<?xml version="1.0" encoding="utf-8"?>
<shape xmlns:android="http://schemas.android.com/apk/res/android">
    <solid
        android:color="#FFFF0000"/>
    <size
        android:width="1dp"/>
</shape>

app:theme="@style/ThemeOverlay.AppCompat.Dark.ActionBar"
app:popupTheme="@style/ThemeOverlay.AppCompat.Light"
