Android开发之使用150行代码实现滑动返回效果

public void setCallback(Callback mCallback){
 this.mCallback = mCallback;
}
private Callback mCallback;
public interface Callback{
 void onShouldFinish();
}

<yifeiyuan.practice.practicedemos.drager.SwipeBackFrameLayout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:tools="http://schemas.android.com/tools"
android:id="@ id/swipe_back"
android:layout_width="match_parent"
android:layout_height="match_parent"
tools:context="yifeiyuan.practice.practicedemos.drager.SwipeBackActivity">
 <TextView
  android:layout_width="40dp"
  android:layout_height="match_parent"
  android:text="@string/hello_world"
  android:gravity="center"
  android:background="#ffff00"
  />
 <View
  android:layout_width="match_parent"
  android:layout_height="match_parent"
  android:background="#ff00ff"
  />
</yifeiyuan.practice.practicedemos.drager.SwipeBackFrameLayout>

//1f代表灵敏度
mDragHelper = ViewDragHelper.create(this, 1f,new ViewDragHelper.Callback() {
 @Override
 public boolean tryCaptureView(View child, int pointerId) {
  return false;
 }
}
//因为我们是从左向右滑动 所以设置EDGE_LEFT
mDragHelper.setEdgeTrackingEnabled(ViewDragHelper.EDGE_LEFT);

private View mDividerView;
private View mContentView;
@Override
protected void onFinishInflate() {
 super.onFinishInflate();
 mDividerView = getChildAt(0);
 mDividerView.setAlpha(0f);
 mContentView = getChildAt(1);
}

@Override
public boolean onInterceptTouchEvent(MotionEvent ev) {
 return mDragHelper.shouldInterceptTouchEvent(ev);
}

@Override
public boolean onTouchEvent(MotionEvent event) {
 mDragHelper.processTouchEvent(event);
 return true;
}

@Override
public void onEdgeTouched(int edgeFlags, int pointerId) {
 super.onEdgeTouched(edgeFlags, pointerId);
 //触摸到左边界的时候 我们capture住mContentView
 mDragHelper.captureChildView(mContentView, pointerId);
}
@Override
public int getViewHorizontalDragRange(View child) {
  return 1;
}

@Override
public void onViewPositionChanged(View changedView, int left, int top, int dx, int dy) {
  super.onViewPositionChanged(changedView, left, top, dx, dy);
  Log.d(TAG, "onViewPositionChanged() called with left = ["   left   "], top = ["   top   "], dx = ["   dx   "], dy = ["   dy   "]");
  //0.0 - 1.0
  //Notice 这边可以给个接口回调出去,就可以做各种炫酷的效果了
  float alpha = (float) (left*1.0/mDividerWidth);
  mDividerView.setAlpha(alpha);
}
  @Override
  public int clampViewPositionHorizontal(View child, int left, int dx) {
//    Log.d(TAG, "clampViewPositionHorizontal() called with dx = ["   dx   "]");
  // 计算left 我们的目标范围是0-dividerwidth的宽度
  mLastdx = dx;
  int newLeft = Math.min(mDividerWidth, Math.max(left,0));
  return newLeft;
}
  @Override
  public void onViewReleased(View releasedChild, float xvel, float yvel) {
  //>0代表用户想关闭
  if (mLastdx>0){
  // 还不到关闭条件,我们让view滑动过去,再关闭
  if (mDividerWidth != releasedChild.getLeft()) {
  mDragHelper.settleCapturedViewAt(mDividerWidth,releasedChild.getTop();
  invalidate();
} else {
  if (mCallback != null) {
   mCallback.onShouldFinish();
  }
}
}else{
  //用户不想关闭 ,则滑动到最左边
  if (mDividerWidth != 0) {
   mDragHelper.settleCapturedViewAt(0, releasedChild.getTop());
   invalidate();
  }
}
}
  @Override
  public void onViewDragStateChanged(int state) {
    super.onViewDragStateChanged(state);
//滑动停止,并且到达了滑动的判断条件 则回调关闭
if(mDragHelper.getViewDragState()==ViewDragHelper.STATE_IDLE&&mCallback != null&&mDividerWidth==mContentView.getLeft()&&mLastdx>0) {
mCallback.onShouldFinish();
    }
   }
  });

private int mDividerWidth;
@Override
protected void onLayout(boolean changed, int left, int top, int right, int bottom) {
 super.onLayout(changed, left, top, right, bottom);
 mDividerWidth = mDividerView.getWidth();
}
//Notice view 刚初始化的时候就会被调用一次
 @Override
 public void computeScroll() {
  super.computeScroll();
  //  Log.d(TAG, "computeScroll() called with "   "");
 if (mDragHelper.continueSettling(true)) {
  invalidate();
  }
}

//no_anim
<alpha
android:duration="300"
xmlns:android="http://schemas.android.com/apk/res/android"
android:fromAlpha="1.0"
android:toAlpha="1.0"
></alpha>

//out_to_right
<translate
xmlns:android="http://schemas.android.com/apk/res/android"
android:duration="300"
android:fromXDelta="0%"
android:toXDelta="100%"
></translate>

mSwipeBack.setCallback(new SwipeBackFrameLayout.Callback() {
 @Override
 public void onShouldFinish() {
  finish();
  overridePendingTransition(R.anim.no_anim, R.anim.out_to_right);
 }
});
